Mica  electric Insulator parts

  • Mica  electric Insulator parts
  • Mica  electric Insulator parts

Mica electric Insulator parts

    Payment Type: L/C,T/T,Paypal
    Terms of Trade: FOB,CIF,EXW
    Min. Order:  100  Bag/Bags
    Delivery Time: 14 Days
    Packaging: Box In strong cartons,on exporting pallet
    Productivity: 100000
    Brand: NBRAM
    Transportation: Ocean,Land,Air
    Place of Origin: China
    Supply Ability: 100000
    Certificate: UL
    Port: Shanghai or Ningbo

Basic Info

Model No.: NBR

Product Description

Mica Insulator

Mica insulator is an entirely mineral material that basically consists of mica and glass-abinding agent that can be vitrified by fusion.These elements are mixed and combined in powder form, and then heated under pressure:the particles of glass when they melt, cover the flakes of mica to form a compact and hard mass

Glass-mica compounds hold a privileged position among the wide variety of insulators offered to the electrical industry.They are positioned by their temperature of use between plastics and ceramics but they possess the ability to be moulded and to be machined like the former but with the hardness and indestructible qualities of the latter.Mica insulator adds a series of physical and chemical properties to these practical advantages which makes it an entirely exceptional insulator.

Mica insulators can be used for high speed train break resistor, as ideal insulation materials.We provide various types of insulator, R-M52 and R-M259 are two of them.The specifica tion and characteristics are displayed as following tables.

models type M(mm) P(mm) L(mm) pitch weight(kg)
MV-52 A 2 tapped holes 10 12 150 0.22
B 2 tapped holes 10 12 175 0.22
C 1 tapped hole 10 12 150 0.25
1 threaded rod 10 35 150
D 1 tapped hole 10 12 175 0.26
1 threaded rod 12 35 175
MV 259 A 2 tapped holes 8 8 125 0.085
B 2 tapped holes 10 8 150 0.085
D 1 thread rod 8 12 125 0.11
1 thread rod 8 28 125
E 1 tapped hole 8 8 125 0.1
1 thread rod 8 22 125
F 2 threaded rods 8 35 125 0.12
G 2 threaded rods 8 20 125
More models are available,Please contact our staff.

Mica Insulator 1Mica Insulator2
